ASI | Zoom Stereo Microscope

Product description

Viewing head: 45° inclined, 360° rotatable binocular head or rinocular head.
The inter-papillary distance adjustable between 54-75mm;
bothdiopter adjustment of range ±5mm.

  • Eyepiece: Wide field, high-eyepoint eyepiece.
  • Objective: Zoom objective magnification 0.70X-4.5X.
  • Magnification range: between 3.5X-45X.
  • Working distance: 100mm, special maximum working distance can provide more working space for you.
  • Illumination: Built-in and built-out illumination system.

Zoom Stereo Microscope P/N 50253
Lighting P/N 50254
Auxiliary objective Lens 0.5X  P/N 50206
Auxiliary objective Lens 0.75X  P/N 50200
Auxiliary objective Lens 1.5X  P/N 50231
Auxiliary objective Lens 2.0X  P/N 50232

Additional information

Manufacturer

Specifications



Eyepiece Standard specification Auxiliary objective 0.5X Auxiliary objective 1.5X Auxiliary objective 2X
Working distance 100mm Working distance 165mm Working distance 45mm Working distance 30mm
Magnification View field Magnification View field Magnification View field Magnification View field
10X/20mm 7.0X 28.6mm 3.5X 57.1mm 10.5X 19mm 14X 14.3mm
45.0X 4.4mm 22.5X 8.9mm 67.5X 3mm 90X 2.2mm
15X/15mm 10.5X 21.1mm 5.25X 42.8mm 15.75X 14.3mm 21X 10.7mm
67.5X 3.3mm 33.75X 6.7mm 101.25X 2.2mm 135X 1.7mm
20X/10mm 14.0X 14.3mm 7.0X 28.6mm 21.0X 9.5mm 28X 7.1mm
90.0X 2.2mm 45.0X 4.4mm 135.0X 1.5mm 180X 1.1mm
